Notice on the X8R9/X8R10 receiver with V2 RF Module

 1. X8R9/X8R10 receiver will output corresponding signal in CH 9,CH 10 only when working with  transmitter that comes with 9-10 channel under PPM mode(such as JR 9XII transmitter, that with 9chs  in PPM mode). That means for transmitter without 9-10 channels under PPM mode(such as Futaba  style transmitter,which have 8chs max at PPM mode), X8R9/X8R10 receiver's CH9, CH10 will not  deliver.

 2. Any receiver need to be binded with the transmitter for the first time being used. Re-bind will be  needed when this happened: after you use a X8R9/X8R10 binded to your transmitter and find that the  other receivers ( 8 channel or below receivers ) which binded before lost binding or can't be operate  correctly, you need use one 8 chs or below Rx binding again. After re-bind, your 8chs or below    receivers back to correct control and your X8-R9/R10 can be use too,just with 8chs deliver only, CH9  and CH10 will without signal out. In some special transmitter,such as JR 9XII,which with 9chs signal  out at PPM mode and when you want use CH9's signal in one model, you need re-binding your  X8 - R9/R10 before use it, and when you return to other Rxs which have 8chs or below in other  models, you need use one Rx re-binding.
